Parker 80UT220BBPGN24H - Low Pressure Spin-On Filters 12AT/50AT Series

Our rebranded Spin-On Low Pressure Filter Series are cost effective yet uncompromising in performance and quality. Max allowable operating pressure of 150 PSI/10.3 Bar and capable of flows up to 50 GPM/190 LPM depending on viscosity.

AFP Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 80UT220BBPGN24H

$528.34/each

Products specifications

Attribute name	Attribute value
UOM	EA	Mounting Type	Inline
Bypass Valve Pressure Rating	25 psid	Filter Element Type	20 micron microglass
Indicator Pressure Setting	1.4	Division	Engine Mobile Hydraulic and Fuel Filtration Division
Maximum Operating Temperature	225	Options	Inlet & Outlet, both sides (all ports drilled & tapped)
Indicator Type	Sold separately	For Fluid Type	Suitable for use with mineral and vegetable oils, and some synthetic oils. For other fluids, please e-mail Technical Support at [email protected] or call 800-253-1258.
Pressure Rating	10.3	Port Type	1-1/2" NPT ports
Flow Rate	80	Housing Material	Low Carbon Steel
Seal Material	Nitrile	Weight	8.6
Compatible Element	929446	Seal Material	Nitrile
Options	Inlet & Outlet, both sides (all ports drilled & tapped)	Filter Element	20 micron microglass
Indicator Type	Sold separately	Flow Rate (gpm)	80
Bypass Valve (psi)	25 psid bypass	Port Connection Type	1-1/2" NPT ports
