Parker 80UT103CBPGN24H - Low Pressure Spin-On Filters 12AT/50AT Series

Our rebranded Spin-On Low Pressure Filter Series are cost effective yet uncompromising in performance and quality. Max allowable operating pressure of 150 PSI/10.3 Bar and capable of flows up to 50 GPM/190 LPM depending on viscosity.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 80UT103CBPGN24H

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Mounting Type	Inline	Seal Material	Nitrile
Division	Engine Mobile Hydraulic and Fuel Filtration Division	Options	Inlet & Outlet, both sides (all ports drilled & tapped)
For Fluid Type	Suitable for use with mineral and vegetable oils, and some synthetic oils. For other fluids, please e-mail Technical Support at [email protected] or call 800-253-1258.	Indicator Type	Sold separately
Pressure Rating	150	Housing Material	Low Carbon Steel
Filter Element Type	3 micron cellulose	Indicator Pressure Setting	20
Bypass Valve Pressure Rating	25	Maximum Operating Temperature	225
Compatible Element	926541	Flow Rate	272
Weight	6.9	Port Type	1-1/2" NPT ports
Seal Material	Nitrile	Options	Inlet & Outlet, both sides (all ports drilled & tapped)
Filter Element	3 micron cellulose	Indicator Type	Sold separately
Flow Rate (gpm)	72	Bypass Valve (psi)	25 psid bypass
Port Connection Type	1-1/2" NPT ports
