Parker 80AT210BBPGY32H - Low Pressure Spin-On Filters 12AT/50AT Series

Our rebranded Spin-On Low Pressure Filter Series are cost effective yet uncompromising in performance and quality. Max allowable operating pressure of 150 PSI/10.3 Bar and capable of flows up to 50 GPM/190 LPM depending on viscosity.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 80AT210BBPGY32H

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Weight	5.89	Compatible Element	929445
Maximum Operating Temperature	225	For Fluid Type	Suitable for use with mineral and vegetable oils, and some synthetic oils. For other fluids, please e-mail Technical Support at [email protected] or call 800-253-1258.
Seal Material	Nitrile	Port Type	2" SAE Code 61 Flange / 1-1/2" NPT ports
Options	Inlet & Outlet, both sides (all ports drilled & tapped)	Division	Engine Mobile Hydraulic and Fuel Filtration Division
Mounting Type	Inline	Indicator Type	Sold separately
Housing Material	Low Carbon Steel	Flow Rate	80
Bypass Valve Pressure Rating	1.7 bar	Pressure Rating	10.3
Indicator Pressure Setting	1.4	Filter Element Type	Canister
Indicator Type	Sold separately	Options	Inlet & Outlet, both sides (all ports drilled & tapped)
Flow Rate (gpm)	80	Port Connection Type	2" SAE Code 61 Flange / 1-1/2" NPT ports
Filter Element	10 micron microglass	Seal Material	Nitrile
Bypass Valve (psi)	25 psid bypass
