Parker 80AT125CBPGY32H - Low Pressure Spin-On Filters 12AT/50AT Series

Our rebranded Spin-On Low Pressure Filter Series are cost effective yet uncompromising in performance and quality. Max allowable operating pressure of 150 PSI/10.3 Bar and capable of flows up to 50 GPM/190 LPM depending on viscosity.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 80AT125CBPGY32H

$406.30

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Pressure Rating	10.3
For Fluid Type	Suitable for use with mineral and vegetable oils, and some synthetic oils. For other fluids, please e-mail Technical Support at [email protected] or call 800-253-1258.	Seal Material	Nitrile
Division	Engine Mobile Hydraulic and Fuel Filtration Division	Port Type	2" SAE Code 61 Flange / 1-1/2" NPT ports
Compatible Element	926170	Options	Inlet & Outlet, both sides (all ports drilled & tapped)
Maximum Operating Temperature	107	Bypass Valve Pressure Rating	1.7 bar
Housing Material	Low Carbon Steel	Flow Rate	272
Filter Element Type	Canister	Mounting Type	Inline
Indicator Type	Sold separately	Indicator Pressure Setting	20
Weight	11.3	Bypass Valve (psi)	25 psid bypass
Flow Rate (gpm)	72	Port Connection Type	2" SAE Code 61 Flange / 1-1/2" NPT ports
Options	Inlet & Outlet, both sides (all ports drilled & tapped)	Indicator Type	Sold separately
Seal Material	Nitrile	Filter Element	25 micron cellulose
