Parker 80AT103CBPGY32H - Low Pressure Spin-On Filters 12AT/50AT Series

Our rebranded Spin-On Low Pressure Filter Series are cost effective yet uncompromising in performance and quality. Max allowable operating pressure of 150 PSI/10.3 Bar and capable of flows up to 50 GPM/190 LPM depending on viscosity.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 80AT103CBPGY32H

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Indicator Type	Sold separately	Housing Material	Low Carbon Steel
Bypass Valve Pressure Rating	1.7 bar	Weight	5.13
Mounting Type	Inline	Indicator Pressure Setting	20
Compatible Element	926541	For Fluid Type	Suitable for use with mineral and vegetable oils, and some synthetic oils. For other fluids, please e-mail Technical Support at [email protected] or call 800-253-1258.
Port Type	2" SAE Code 61 Flange / 1-1/2" NPT ports	Maximum Operating Temperature	225
Filter Element Type	3 micron cellulose	Pressure Rating	150
Flow Rate	272	Options	Inlet & Outlet, both sides (all ports drilled & tapped)
Division	Engine Mobile Hydraulic and Fuel Filtration Division	Seal Material	Nitrile
Flow Rate (gpm)	72	Seal Material	Nitrile
Bypass Valve (psi)	25 psid bypass	Filter Element	3 micron cellulose
Port Connection Type	2" SAE Code 61 Flange / 1-1/2" NPT ports	Indicator Type	Sold separately
Options	Inlet & Outlet, both sides (all ports drilled & tapped)
