Parker 8 T22X-S - Triple-Lok® 37° Flare JIC Tube Fittings and Adapters

Parker Triple-Lok 37° Flare JIC Tube Fittings and Adapters are a reliable leak-free metal to metal connection solution for most high pressure hydraulic applications.

AFP Availability:	Quote Required
Partner Available:	70 In Stock

Brand Parker

Part No. 8 T22X-S

$9.90/each

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 3 Thread Size	na
Connection 3 Tube Outside Diameter	na	O-Ring Material	na
Connection Type	37° Flare	Connection 1 Tube Outside Diameter	1/2 inch
Dimensional Weight	0.039568345323741004 lb	Connection 2 Size	Male Bolt Threads
Division	Tube Fittings Division	Body Material	Steel
Connection 4 Tube Outside Diameter	na	Connection 1 Size	Female 37° Flare
Maximum Dynamic Pressure	6000 psi	Specifications Met	SAE J514
Connection 4 Size	na	Connection 3 Size	na
Shape	Cap	Connection 2 Tube Outside Diameter	na
Connection 2 Thread Size	na
