| UOM | EA | Port Type | NPT |
| Specifications Met | EMC | Maximum Pressure Differential | 150.0 psi |
| Maximum Fluid Temperature | 150 °F | Orifice Size | 1/4 inch |
| Preventive Maintenance Kit | 7K701 | Power Consumption | 10 W |
| Seal Material | NBR - Low Temp | Installation | IOM 7505 |
| Actuation Type | Internal Pilot | Override Functionality | n/a |
| Insulation Class | F (155°C) | Division | Fluid Control Division |
| Maximum Ambient Temperature | 167 °F | Coil Type | 1/2" NPT Conduit with 18" Leads |
| Function | Single Solenoid | Minimum Fluid Temperature | -40 °F |
| Valve Type | 4-Way (5/2) | Body Material | Brass |
| Input Voltage | 120/60 VAC | Main Flow Coefficient | 1.2 Cv |
| Minimum Pressure Differential | 30 psi | Media | Inert Gases |
| Ingress Protection Rating | CSA Class 2, Div. 1, Group E,F,G to T3C | Port Size | 1/4 inch |
| Port Type | NPT | Body Material | BRASS |
| Input Voltage | 120/60, 110/50 | Actuation Type | Internally Piloted |
| Insulation Class | Class F | Maximum Fluid Temperature | 150.0 |
| Maximum Pressure Differential | 150.0 | Maximum Ambient Temperature | 167.0 |
| Port Size | 1/4 | Power Consumption | 10.0 |
| Ingress Protection Rating | UL, CSA - Class 1, Div. 1, Group A,B,C,D Class 2, Div. 1, Group E,F,G - T3C | Coil Type | 1/2" NPT Conduit with 18" Leads |
| Media | Air, Inert Gas | Function | 2 Position, Single Solenoid |
| Valve Type | 4 Way (5/2) | Installation | IOM 7701 |
| Orifice Size | 1/4 | Seal Material | NBR - Low Temp |
| Specifications Met | UL, CSA Listed General Purpose Valve for Hazardous Locations; SIL 3; CE - Low Voltage, EMC | Main Flow Coefficient | 1.2 |
| Minimum Fluid Temperature | -40.0 | Preventive Maintenance Kit | 7K701 |
| Minimum Pressure Differential | 30.0 | | |
