Parker 73317BN4UN00N0C111C2 - Parker 3-Way Normally Closed, 1/2" NPT General Purpose Solenoid Valves

Parker 3-Way Normally Closed, 1/2" NPT Solenoid Valves provide operating pressures up to 4.0 psi and flow factors up to 180 CV's. They offer a brass body, multiple mounting positions and coil options for all general purpose flow control applications.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 73317BN4UN00N0C111C2

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Port Size	1/2	Port Type	NPT
Input Voltage	24.0	Body Material	Brass
Division	Fluid Control Division	Media	General Purpose for Air
Function	Normally Closed (NC)	Coil Type	1/2" NPT Conduit, 18" Leads, Class F, NEMA 4X
Valve Type	3-Way	Seal Material	NBR
Orifice 2 Size	n/a	Number of Ports	3
Flow Coefficient 2	n/a	Coil Specifications Met	NEMA 4X
Maximum Fluid Temperature	150	Minimum Fluid Temperature	0
Additional Options	No Option	Maximum Pressure Differential	150 psi (DC)
Exhaust Flow Coefficient	n/a	Main Flow Coefficient	4
Exhaust Orifice Size	n/a	Actuation Type	Manual
Product Series	7000 Series	Power Consumption	10 W (DC)
Main Orifice Size	1/4	Minimum Pressure Differential	30
Coil Type	1/2" NPT Conduit, 18" Leads, Class F, NEMA 4X	Voltage (V)	24 VDC
Mechanical Option	No Option	Maximum Pressure Differential (psi)	150 psi (DC)
Power (Watts)	10 Watt (DC)	Orifice Main (inch)	1/4
Flow Factor Main (Cv)	4
