| Division | TAIYO Division | Fluid Type | Petroleum-based fluid(When using another fluid,give us such instructions.) |
| Cushioning Type | Metal fitting system | Screw Tolerance | JIS 6g/6H |
| Seal Material | 2:Urethane rubber(standard) 1:Nitrile rubber 3:Fluorocarbon | Speed Range | 10-500mm/s(φ40-140), 20-500mm/s(φ160-250) |
| Mounting Style | SD,LA,FA,FB,CA,TC | Rod End Styles | Rod eye(T-end),Rod clevis(Y-end),Lock nut |
| Bellows Material | Standard：Nylon tarpaulin, Semi-standard：Chloroprene, Conex | Bore Diameter (mm) | 40, 50, 63, 80, 100, 125, 140, 160, 180, 200, 224, 250 |
| Temperature Range (C) | -10-+80 (ambient/fluid temperature, No freezing) | Stroke Length Tolerance (mm) | 0-+0.8(0-100mm), 101-250mm:0-+1.0(101-250mm), 0-+1.25(251-630mm), 0-+1.4(631-1000mm), 0-+1.6(1001-1600mm), 0-+1.8(1601-2000mm) |
| Minimum Operating Pressure (MPa) | 0.3(φ40-140), 0.5(φ160-250) | Color | Munsell7.5BG5.5/2.5 |
| Rod Type | Rod B, Rod A | Type | Double Acting Single Rod, 7MPa |
| Proof Pressure (MPa) | 17 | Nominal Pressure (MPa) | 7 |
| Maximum Working Pressure (MPa) | 14 | | |
