Parker 690RHH10MTC - Fuel Filter Water Separator – Racor Spin-on Series

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 690RHH10MTC

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Division	Engine Mobile Original Equipment Division	Operating Temperature	-40 to 250 °F
Filter Element Type	10 Micron Aquabloc Spin-on	Product Type	Diesel Spin-on FF/WS
Number of Ports	2 Inlet / 2 Outlet	Compatible Element	R90SL-D-MAX = "2" Micron<br/>R90T-D-MAX = 10 Micron<br/>R90P-D-MAX = 30 Micron
Accessories Included	See Product Support Tab	Width	108.0 mm
Head Material	Aluminium Alloy	Brand	Racor
Clean Pressure Drop	0.29 psi	Depth	4.6 inch
Maximum Fluid Temperature	190.0 °F	Weight	1.2 kg
Maximum Operating Pressure	30 psi	For Fluid Type	Diesel
Height	11.8 inch	Port Size	M16 1.5 SAE
Micron Rating	98% @ 10 Micron	Mounting	Bracket Included
Product Series	Diesel Spin-on 600	Location	EMEA region only
Part Type	Filter Assembly	Bowl Type	Deep Bowl, Clear Engineering Plastic
Heater Power Rating	In Head PTC Heater (12V to 24V) (Diesel Only)	Integral Primer Pump Included	No Pump
Bowl Material	Clear Engineering Plastic	Flow Rate	90 gph (341 lph)
