Parker 690R10 - Fuel Filter Water Separator – Racor Spin-on Series

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 690R10

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Compatible Element	R90S = "2" Micron<br/>R90T = 10 Micron<br/>R90P = 30 Micron	Width	4.5 inch
Height	11.2 inch	For Fluid Type	Diesel and Gasoline
Depth	114.0 mm	Number of Ports	2 Inlet / 2 Outlet
Filter Element Type	10 Micron Aquabloc Spin-on	Product Type	Diesel Spin-on FF/WS
Operating Temperature	-40 to 250 °F	Weight	1.2 kg
Maximum Fluid Temperature	190.0 °F	Head Material	Aluminium Alloy
Clean Pressure Drop	2 kPa	Brand	Racor
Division	Engine Mobile Original Equipment Division	Maximum Operating Pressure	207.0 kPa
Accessories Included	See Product Support Tab	Product Series	Diesel Spin-on 600
Port Size	3/8"-18 NPTF (SAE J476)	Flow Rate	90 gph (341 lph)
Bowl Material	Clear Engineering Plastic	Part Type	Filter Assembly
Location	North America and EMEA regions	Heater Power Rating	No Heater
Mounting	Bracket Included	Micron Rating	98% @ 10 Micron
Integral Primer Pump Included	No Pump	Bowl Type	Standard, Clear Engineering Plastic

Product resources

Literature and Reference Materials

Literature and Reference Materials, Selector Guides

Racor--600 Diesel Spin-on--RSL0367 (PDF)
