Parker 59-1002-16FO - Non-Spill, Flat Face Hydraulic ACME Thread to Connect Quick Couplings - 59 Series

Parker's non-spill, flat face connect under pressure hydraulic couplers and nipples are heavy duty for use in high pressure, high impulse hydraulic applications where fluid lines require fast and easy connection and disconnection.

AFP Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 59-1002-16FO

$460.10/each

Products specifications

Attribute name	Attribute value
UOM	EA	Dimensional Weight	0.2785611510791367 lb
Valve Type	Non-spill	Maximum Operating Temperature	250 °F
Division	Quick Coupling Division	Media	Hydraulic
Body Material	Steel	Division	Quick Coupling Division
Thread Size	Female	Plating Type	Zinc-nickel Black FNC Coating
Application	High Pressure Hydraulics	Minimum Operating Temperature	-40 °F
Maximum Operating Pressure	6000 psi	Seal Material	Polyurethane/Nitrile
Coupling Half	Nipple	Body Size (inch)	1
Connection Thread Size (inch)	1 5/16 - 12	Connection Type	UNF
Maximum Working Pressure (psi)	6000
