Parker 50AT125CBPPN20H - Low Pressure Spin-On Filters 12AT/50AT Series

Our rebranded Spin-On Low Pressure Filter Series are cost effective yet uncompromising in performance and quality. Max allowable operating pressure of 150 PSI/10.3 Bar and capable of flows up to 50 GPM/190 LPM depending on viscosity.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 50AT125CBPPN20H

$90.16

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Mounting Type	Inline
Seal Material	Nitrile	Division	Engine Mobile Hydraulic and Fuel Filtration Division
Options	Inlet & Outlet, both sides (all ports drilled & tapped)	For Fluid Type	Suitable for use with mineral and vegetable oils, and some synthetic oils. For other fluids, please e-mail Technical Support at [email protected] or call 800-253-1258.
Indicator Type	Sold separately	Pressure Rating	10.3
Housing Material	Low Carbon Steel	Filter Element Type	Canister
Indicator Pressure Setting	2.5	Bypass Valve Pressure Rating	3
Maximum Operating Temperature	225	Weight	1.77
Flow Rate	22	Port Type	1-1/4" NPT ports
Compatible Element	926170	Seal Material	Nitrile
Options	Inlet & Outlet, both sides (all ports drilled & tapped)	Filter Element	25 micron cellulose
Indicator Type	Sold separately	Bypass Valve (psi)	3
Flow Rate (gpm)	6	Port Connection Type	1-1/4" NPT ports

Product resources

Literature and Reference Materials
