Picture of Parker 4120MAM30 - Marine Fuel Filter Water Separator – Racor Spin-on Series

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker 4120MAM30 - Marine Fuel Filter Water Separator – Racor Spin-on Series

Racor Marine Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. UL-approved versions available.
Availability:
Quote Required
Partner Available:Quote Required
Brand Parker
Part No. 4120MAM30
TBD
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
DivisionEngine Mobile Original Equipment DivisionBrandRacor
Clean Pressure Drop0.5 psiOperating Temperature-40 to 121 °C
Number of Ports2 Inlet / 2 OutletFilter Element Type30 Micron Aquabloc Spin-on
Head MaterialPower Coated Aluminium AlloyMounting TypeBracket Included
Maximum Fluid Temperature190.0 °FProduct SeriesDiesel Spin-on
Weight3.3 lb / 1.5 KgCompatible ElementS3201PUL = 30 micornS3201TUL = 10 micron<br/>S3201S = 2 micron
Maximum Operating Pressure15 psiDepth12.2 cm
Width4.5 inchHeight32.5 cm
Micron Rating98% @ 30 MicronBowl MaterialAluminum Bowl
Filtered MediumDieselUL CertificationYes
Integral Primer PumpYesFlow Rate120 gph / 454 lph
Port Size3/4" SAE
Product resources

Literature and Reference Materials

Distributor Support, Literature and Reference Materials, Selector Guides

Compliance, Certifications & Safety, Literature and Reference Materials
