Parker 3C20EF-EF25 - Soft Seat, In Line Hydraulic Check Valves - S6C and 3C Series

Parker's, in line check valves are one way flow control devices used primarily in hydraulic systems to eliminate potential damage caused by fluid back pressure.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 3C20EF-EF25

$295.48

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Division	Quick Coupling Division
Maximum Operating Pressure	3000 psi	Body Material	Steel
Configuration	n/a	Mounting Type	Threaded
Actuation Type	Mechanical	Connection Size	1-5/8"-12 UN inch
Maximum Operating Temperature	-40 °F	Minimum Operating Temperature	400 °F
Seat Type	Soft Seat	Flow Direction	n/a
Connection Type	Female SAE ORB to Female SAE ORB	Maximum Flow Rate	90 Gal/min
Seal Material	Fluorocarbon	Body Size (inch)	1 1/4
Inlet Port Size (inch)	1 5/8 - 12 UN	Cracking Pressure (psi)	25
Outlet Port Size (inch)	1 5/8 - 12 UN	Inlet Port Connection Type	Female SAE Straight Thread
Outlet Port Connection Type	Female SAE Straight Thread
