| Division | TAIYO Division | Body Material | Stainless Steel |
| Cushioning Type | Metal fitting system | Screw Tolerance | JIS 6g/6H |
| Type | Double Acting Single Rod, Switch set | Bore Diameter (mm) | 32, 40, 50, 63, 80, 100 |
| Seal Material | 1:Nitrile rubber 8:Slipper Seal | Output Type | Standard:12V DC voltage output Phase A & B (90°phase)30mA or less Semi-standard:NPN open collector output Phase A & B (90°phase)Applied voltage : 24 V DC or less Sink current:30mA or less |
| Speed Range | 8-300mm/s(U seal), 0.1-300mm/s(Slipper seal) | Mounting Style | SD,LA,LB,FG,FH,CT |
| Resolution (mm) | 0.1mm/Pulse | Rod End Styles | Rod eye (T-end), rod clevis (Y-end) with pin, Floating joint(F-end:Do not use together with Mounting style CT accessories.) |
| Operating Humidity | 90%RH(no condensing) | Proof Pressure (MPa) | 5 |
| Input Supply Voltage | Standard:12 DC, Semi-standard:12V-24 DC | Temperature Range (C) | -10-+50 (No freezing) |
| Nominal Pressure (MPa) | 3.5 | Stroke Length Tolerance (mm) | 0-+1.0(0-250mm), 0-+1.4(251-1000mm), 0-+1.8(1001-1800mm) |
| Length Measuring Error (mm/m) | 0.5 (Length measuring error per meter of total moving distance) | Maximum Response Speed (mm/s) | 300 |
| Maximum Working Pressure (MPa) | 4.5 | Minimum Operating Pressure (MPa) | 0.2 |
