Parker 3250R - Fuel Filter Water Separator – Racor Spin-on Series

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 3250R

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Division	Engine Mobile Original Equipment Division
Brand	Racor	Product Type	Diesel Spin-on FF/WS
Maximum Operating Pressure	7	Head Material	Aluminium Alloy
For Fluid Type	Diesel and Gasoline	Filter Element Type	10 Micron Aquabloc Spin-on
Accessories Included	See Product Support Tab	Operating Temperature	-40 to 250
Maximum Fluid Temperature	190.0	Number of Ports	1 Inlet / 1 Outlet
Depth	4.75	Width	5.5
Height	17.25	Weight	4.6 lb / 2.1 Kg
Compatible Element	S3207S = "2" Micron<br/>S3207T = 10 Micron<br/>S3207P = 30 Micron	Clean Pressure Drop	1
Location	North America and EMEA regions	Micron Rating	98% @ 10 Micron
Mounting	Bracket Included	Part Type	Filter Assembly
Bowl Material	Clear Engineering Plastic	Heater Power Rating	No Heater
Integral Primer Pump Included	No Pump	Bowl Type	Deep Bowl, Clear Engineering Plastic
Port Size	7/8"-14 UNF (SAE J1926)	Product Series	Diesel Spin-on 300
Flow Rate	250 gph (946 lph)
