Parker 318P-12PP - Plastic Barbed Fittings, Parker Par-Barbs

Parker's Par-Barb fttings are specially engineered with a four-barb design that generates maximum gripping and sealing power when combined with a hose clamp.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 318P-12PP

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Division	Fluid System Connectors Division	Media	Water, Air, Other Compatible Fluids
Specifications Met	FDA, NSF-51	Maximum Operating Pressure	125 psi
Maximum Operating Temperature	104 °C	Minimum Operating Temperature	-12 °C
Application	Chemical Dispensing, Pneumatic Systems, Food Processing, Beverage Dispensing	Tube Material	Vinyl, Polyurethane, Rubber Hose
Compatible Tube	Vinyl	Connection 3 Type	N/A
Connection 2 Type	n/a	Configuration	Pipe to Pipe
Division	Fluid System Connectors Division	Connection 1 Type	Male NPT
Connection 1 Size	3/4	Connection 2 Size	n/a
Shape	Hex Plug	Vacuum Pressure Rating	-29
Body Material	Polypropylene	Technology	Fluid & Gas Handling
Brand	Parker	Color	Black
Connection 3 Size	N/A	Connection 1 Type	Male Pipe
Connection 2 Hose I.D. (inch)	n/a	Body Material	Polypropylene, Black
Connection 1 Thread Size	3/4"	Connection 1 Hose I.D. (inch)	n/a
Product Style	Male Pipe	Connection 3 Size	N/A
Connection 3 Type	N/A	Connection 2 Size	N/A
Shape	Hex Plug	Color	Black
Connection 2 Type	N/A	Configuration	Pipe to Pipe
Connection 1 Size	3/4"

Product resources

Compliance, Certifications & Safety

Literature and Reference Materials

Compliance, Certifications & Safety, Literature and Reference Materials

FSC REACH Product Declaration (PDF)
