Parker 3150R - Fuel Filter Water Separator – Racor Spin-on Series

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 3150R

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Division	Engine Mobile Original Equipment Division	Brand	Racor
Product Type	Diesel Spin-on FF/WS	Maximum Operating Pressure	7
Head Material	Aluminium Alloy	For Fluid Type	Diesel and Gasoline
Filter Element Type	10 Micron Aquabloc Spin-on	Accessories Included	See Product Support Tab
Operating Temperature	-40 to 250	Maximum Fluid Temperature	190.0
Number of Ports	1 Inlet / 1 Outlet	Weight	3.6 lb / 1.6 Kg
Depth	4.75	Width	5.5
Height	13.6	Compatible Element	S3238 = 10 Micron<br/>S3238P = 30 Micron
Clean Pressure Drop	0.68	Location	North America and EMEA regions
Micron Rating	98% @ 10 Micron	Mounting	Bracket Included
Part Type	Filter Assembly	Bowl Material	Clear Engineering Plastic
Heater Power Rating	No Heater	Integral Primer Pump Included	No Pump
Bowl Type	Deep Bowl, Clear Engineering Plastic	Flow Rate	150 gph (568 lph)
Port Size	7/8"-14 UNF (SAE J1926)	Product Series	Diesel Spin-on 300
