Parker 309P-4-2N - Plastic Barbed Fittings, Parker Par-Barbs

Parker's Par-Barb fttings are specially engineered with a four-barb design that generates maximum gripping and sealing power when combined with a hose clamp.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 309P-4-2N

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Division	Fluid System Connectors Division	Minimum Operating Temperature	-40 °F
Specifications Met	FDA	For Fluid Type	Water
Maximum Operating Temperature	93 °C	Application	Beverage Dispensing
Maximum Operating Pressure	8.5 bar	Dimensional Weight	0.5755 lb
Shape	Reducer Bushing	Media	Water
Connection 2 Size	1/8	Vacuum Pressure Rating	-29
Brand	Parker	Connection 3 Size	N/A
Compatible Tube	Vinyl	Connection 1 Size	1/4
Connection 3 Type	N/A	Configuration	Pipe to Pipe
Technology	Fluid & Gas Handling	Color	White
Body Material	Nylon	Division	Fluid System Connectors Division
Connection 1 Type	Male NPT	Connection 2 Type	Female NPT
Product Style	Female Pipe to Male Pipe	Connection 1 Type	Male Pipe
Connection 2 Type	Female Pipe	Connection 2 Hose I.D. (inch)	n/a
Connection 2 Thread Size	1/8"	Body Material	Nylon,White
Connection 1 Thread Size	1/4"	Connection 1 Hose I.D. (inch)	n/a
Connection 1 Size	1/4"	Color	White
Configuration	Pipe to Pipe	Shape	Reducer Bushing
Connection 3 Size	N/A	Connection 3 Type	N/A
Connection 2 Size	1/8"
