Parker 255IFHD-4 - Union Elbow 255IFHD

Parker 45° Inverted Flare Brass Union Elbow - Ref. SAE J512 040427

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 255IFHD-4

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Material	Brass
Pkg Qty	1	Outer Diameter 1	1/4 Inch
Thread 1	7/16-24 UN/UNF	Thread 2	7/16-24 UN/UNF
Outer Diameter 2	1/4 Inch	Parker Group	Fluid Connector
Inch/Metric	Inch	Material	Brass
Parker Division	Fluid Systems Connector (Brass Products)	Outer Diameter 1 Inch/mm	Inch
Configuration Type	Flare to Flare	Thread 1 Type	UN/UNF
Operating Temperature	-65°F to +250°F	Thread 2 Type	UN/UNF
Outer Diameter 2 Inch/mm	Inch	Outer Diameter 1	1/4 Inch
Series	45° Inverted Flare	Thread 1	7/16-24 UN/UNF
Thread 2	7/16-24 UN/UNF	Configuration Sub-Type	Union Elbow 90°
Outer Diameter 2	1/4 Inch	Pressure Rating	1400 PSI
SAE Compliance	J512	SAE Reference	SAE 040427
Body Shape	Extruded
