Parker 245R30MTC - Fuel Filter Water Separator – Racor Spin-on Series

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 245R30MTC

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Division	Engine Mobile Original Equipment Division	Brand	Racor
Operating Temperature	-40 to 121 °C	Product Type	Diesel Spin-on FF/WS
Head Material	Aluminium Alloy	For Fluid Type	Diesel and Gasoline
Filter Element Type	30 Micron Aquabloc Spin-on	Accessories Included	See Product Support Tab
Maximum Operating Pressure	207.0 kPa	Depth	102.0 mm
Width	102.0 mm	Number of Ports	1 Inlet / 2 Outlet
Maximum Fluid Temperature	190.0 °F	Weight	2.2 lb / 1 Kg
Height	267.0 mm	Compatible Element	R25S = "2" Micron<br/>R25T = 10 Micron<br/>R25P = 30 Micron
Clean Pressure Drop	4.21 kPa	Micron Rating	98% @ 30 Micron
Mounting	Bracket Included	Bowl Type	Standard, Clear Engineering Plastic
Part Type	Filter Assembly	Bowl Material	Clear Engineering Plastic
Heater Power Rating	No Heater	Location	EMEA region only
Port Size	M14 1.5 SAE	Product Series	Diesel Spin-on 200
Integral Primer Pump Included	Hand Plunger Priming Pump (Diesel or Gasoline)	Flow Rate	45 gph (170 lph)
