Picture of Parker 230RMAM30 - Marine Fuel Filter Water Separator – Racor Spin-on Series

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker 230RMAM30 - Marine Fuel Filter Water Separator – Racor Spin-on Series

Racor Marine Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. UL-approved versions available.
Availability:
Quote Required
Partner Available:Quote Required
Brand Parker
Part No. 230RMAM30
TBD
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
DivisionEngine Mobile Original Equipment DivisionBrandRacor
Maximum Operating Pressure30Filter Element Type30 Micron Aquabloc Spin-on
Operating Temperature-40 to 250Maximum Fluid Temperature190.0
Head MaterialPower Coated Aluminium AlloyMounting TypeBracket Included
Product SeriesMarine Spin-on FF/WSDepth4
Width3.9Number of Ports1 Inlet / 2 Outlet
Height10Weight2.0 lb / 0.5 Kg
Compatible ElementR20PUL = 30 micron<br/>R20TUL = 10 micron<br/>R20S = 2 micronClean Pressure Drop0.3
Micron Rating98% @ 30 MicronFlow Rate30 gph / 114 lph
Port Size1/4”-18 NPTFBowl MaterialAluminum Bowl
Filtered MediumDieselUL CertificationYes
Integral Primer PumpYes
