Parker 230RM10MTC - Fuel Filter Water Separator – Racor Spin-on Series

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 230RM10MTC

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Division	Engine Mobile Original Equipment Division	Brand	Racor
Maximum Operating Pressure	30	Product Type	Diesel Spin-on FF/WS
Head Material	Aluminium Alloy	For Fluid Type	Diesel and Gasoline
Filter Element Type	10 Micron Aquabloc Spin-on	Accessories Included	See Product Support Tab
Operating Temperature	-40 to 250	Maximum Fluid Temperature	190.0
Depth	4	Width	4
Number of Ports	1 Inlet / 2 Outlet	Height	9
Weight	2 lb / 0.90 Kg	Compatible Element	R20S = "2" Micron<br/>R20T = 10 Micron<br/>R20P = 30 Micron
Clean Pressure Drop	0.31	Micron Rating	98% @ 10 Micron
Mounting	Bracket Included	Part Type	Filter Assembly
Heater Power Rating	No Heater	Location	EMEA region only
Bowl Type	Standard, Aluminium Alloy	Port Size	M14 1.5 SAE
Product Series	Diesel Spin-on 200	Integral Primer Pump Included	Hand Plunger Priming Pump (Diesel or Gasoline)
Flow Rate	30 gph (114 lph)	Bowl Material	Aluminium Alloy
