Parker 1PDCY-2-2 - Permanent Fittings for Parflex Hose – CY Series

Name: Parker 1PDCY-2-2 - Permanent Fittings for Parflex Hose – CY Series
SKU: 1PDCY-2-2
Price: 40.36 USD
Availability: InStock

Parker CY Series Fittings are a durable, steel, crimp style permanent fittings that are suitable for use with the Parflex HLB Lubrication Line Hose and the 56DH/568DH Diagnostic Hose.

AFP Availability:

1 Limited Stock

North Chesterfield, VA

Partner Available:

Quote Required

Quantities sourced from Partner Network may incur an upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

Brand Parker

Part No. 1PDCY-2-2

$40.36/each

Qty:

Products specifications

Attribute name	Attribute value
UOM	EA	Product Type	Hose Fittings
Specifications Met	n/a	Hex Size 1	n/a
Application	Fluid Control	Connection 1 Type	Hose
Brand	Parker	Industry	Off-road Machinery
Maximum Operating Pressure	414 bar	Configuration	Hose to Port
Fitting Length	61.47 mm	Connection 2 Size	3/14"-16 inch
For Fluid Type	Hydraulic Fluids	Division	Parflex Division
Technology	Fluid & Gas Handling	Hex Size	1.0 inch (see drawing legend H)
Connection 1 Size	1/8 inch Hose I.D.	Connection Length	1-7/8 inch Cut-off allowance
Body Material	Steel	Coating	Chromium 6 Free-plated
Connection 2 Type	UNF Thread	Shape	Straight
Division	Parflex Division	Shape	Straight
Body Material	Steel	Hose I.D. (inch)	0.125"
Length (inch)	2.42"	Product Style	Bulkhead Diagnostic Nipple
Connection 2 Size	3/14"-16 UNF
