*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker 180256 - GLASS-MATE™ PMG Liquid Filter Cartridge

Glass-Mate™ PMG filter cartridges remove contaminants from a wide range of liquid applications. The pleated style cartridges are made using glass media with outer support. Available from 0.2 to 40 micron rating options with variety of end cap options.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 180256

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Division	Industrial Process Filtration Division	Brand	Parker
Product Type	Filter Cartridge	Division	Industrial Process Filtration Division
Industry	Industrial	Technology	Filtration
Application	Liquid Particulate Filtration	Flow Direction	Outside-to-inside
Filter Construction	Pleated	Changeout Pressure Differential	35 psid
pH Range	3-9	Filter Material	Glass with Acrylic
Quantity per Box	6.0	Nominal Inside Diameter	1 inch
Nominal Outside Diameter	2.5 inch	End Cap Configuration	DOE - Double Open End
Seal Material	EPR	End Cap Material	Polypropylene
Maximum Operating Temperature	200 F	Core Material	Glass-Filled Polypropylene
Body Material	Polypropylene Extruded Cage	Micron Rating	0.2
Product Series	PMG	Cartridge Length	19.9375"
Maximum Pressure Differential	90 PSID @ 75 F	Model Number	ELMT PMG002-20FE-DO
Series	N/A	Equalizer Method	N/A
Nominal Capacity (ton)	N/A	Refrigerant Type	R-404A
Connection	N/A	Kit Includes	N/A
Valve Type	N/A	Application	Low Temp Refrigeration
Thermostatic Charge	ZP30	Connection Type	n/a
Type	Element	Element Type	43
Capillary Length (inch)	30"	Strainer Type	N/A
