Parker 164546 - HONEYCOMB™ HFT Wound Depth Liquid Filter Cartridge

Honeycomb™ wound depth filter cartridges remove contaminants from a wide range of liquid applications. Parker strings are known for superior quality and performance. Available from 0.5 to 150 micron ratings with a variety of string materials.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 164546

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Division	Industrial Process Filtration Division	Brand	Parker
Product Type	Filter Cartridge	Division	Industrial Process Filtration Division
Technology	Filtration	Application	Liquid Particulate Filtration
Flow Direction	Outside-to-inside	Quantity per Box	15
Product Series	HFT	Filter Construction	Wound String
Nominal Inside Diameter	1"	Maximum Pressure Differential	60 PSID
Changeout Pressure Differential	30 PSID	Capillary Tube Length	1.52 m mm
Thermostatic Charge	C	Cartridge Length	20"
End Cap Material	N/A	End Cap Configuration	DOE - Double Open End
Industry	Oil & Gas and Industrial	Packaging	Standard
Core Material	304 Stainless Steel	Seal Material	N/A
Core Cover Material	Polypropylene	Nominal Outside Diameter	2.4375"
Maximum Operating Temperature	200 F	Micron Rating	3
Filter Material	Polypropylene (Non-FDA, Industrial Grade)	Model Number	ELMT T27R20GY
Thermostatic Charge	VC	Equalizer Method	External
Application	Medium Temperature Refrigeration	Inlet Connection Size (inch)	3/8
Nominal Capacity (ton)	1/5	Refrigerant Type	R-22/R-407A/R-407C/R-407F/R-448A/R-449A
Outlet Connection Size (inch)	1/2

Product resources

Literature and Reference Materials

HONEYCOMB™ HFT Wound Depth Liquid Filter Cartridge (PDF)
