| Division | TAIYO Division | Body Material | Stainless Steel |
| Type | Cutting oil proof type, Double Acting Single Rod, Switch set | Fluid Type | Petroleum-based fluid(When using another fluid,give us such instructions.) |
| Rod Series | Rod B | Related Parts | Lock nut |
| Rod End Styles | Rod eye(T-end),Rod clevis(Y-end)with pin | Cushioning Type | Metal fitting system |
| Screw Tolerance | JIS 6g/6H | Bore Diameter (mm) | 32, 40, 50, 63, 80 |
| Bellows Adapter Material | Standard：Nylon tarpaulin Semi-standard：Chloroprene,Conex | Minimum Operating Pressure (MPa) | Cap side:0.3 Rod side:0.45 |
| Seal Material | 1:Nitrile rubber 2:Urethane rubber 6:HNBR 8:Combined seal | Speed Range | 8-400mm/s(φ32-63), 8-300mm/s(φ80-125), 8-200mm/s(φ140-160) |
| Mounting Style | SD,LA,EA,EB,FA,FE,FB,CA,CB,TA,TC | Proof Pressure (MPa) | 24 |
| Temperature Range (C) | AX switch:-10-+70 (No freezing) WR,WS switch:-10-+70 (No freezing) | Nominal Pressure (MPa) | 16 |
| Stroke Length Tolerance (mm) | 0-+0.8(0-100mm), 0-+1.0(101-250mm), 0-+1.25(251-630mm), 0-+1.4(631-1000mm), 10-+1.6(1001-1600mm), 0-+1.8(1601-2000mm) | Maximum Working Pressure (MPa) | 20 |
