Parker 155F-10 - Brass 45° Flare Fittings

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 155F-10

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Brand	Parker	Division	Fluid System Connectors Division
Body Material	Brass	Technology	Fluid & Gas Handling
Division	Fluid System Connectors Division	O-Ring Material	Fluorocarbon
Maximum Operating Temperature	121 °C	Minimum Operating Temperature	-53 °C
Application	Pumps, Gas Grills, Coffee Makers, Adapters	Specifications Met	SAE J512, SAE J513
Maximum Operating Pressure	193 bar	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Nut Material	Brass	Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
Product Style	Flare to Flare	Connection 1 Type	Flare
Connection 2 Type	Flare	Connection 1 Thread Size	7/8-14 inch
Connection 2 Thread Size	7/8-14 inch	Connection 1 Tube Outside Diameter	5/8 inch
Connection 2 Tube Outside Diameter	5/8 inch	Connection 3 Tube Outside Diameter	NA
Shape	90° Forged Elbow	Connection 3 Type	NA
Connection 3 Thread Size	NA
