Parker 149F-2-2 - Brass 45° Flare Fittings

Name: Parker 149F-2-2 - Brass 45° Flare Fittings
SKU: 149F-2-2
Price: 8.22 USD
Availability: InStock

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Availability:

9 In Stock

Sumter, SC

Partner Available:

221 In Stock

Brand Parker

Part No. 149F-2-2

$8.22

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Brand	Parker
Division	Fluid System Connectors Division	Body Material	Brass
Technology	Fluid & Gas Handling	Division	Fluid System Connectors Division
Maximum Operating Temperature	250 °F	O-Ring Material	Fluorocarbon
Minimum Operating Temperature	-53 °C	Application	Adapters, Fuels, Natural Gas, Propane, Refrigerant Lines
Dimensional Weight	0.11037769784172662 lb	Specifications Met	SAE J512, SAE J513
Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon	Nut Material	Brass
Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared	Maximum Operating Pressure	193.0 bar
Connection 2 Type	Male Pipe	Connection 1 Type	Flare
Product Style	Flare to Pipe	Connection 1 Thread Size	5/16-24 inch
Connection 1 Tube Outside Diameter	1/8 inch	Connection 3 Tube Outside Diameter	NA
Shape	90° Forged Elbow	Connection 3 Type	NA
Connection 2 Thread Size	1/8 inch	Connection 3 Thread Size	NA
Connection 2 Tube Outside Diameter	NA
