Parker 1495F-12-12 - Brass 45° Flare Fittings

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

AFP Availability:	Quote Required
Partner Available:	5 In Stock

Brand Parker

Part No. 1495F-12-12

$70.02/each

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Operating Temperature	121 °C
Technology	Fluid & Gas Handling	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Body Material	Brass	Nut Material	Brass
Minimum Operating Temperature	-53 °C	Division	Fluid System Connectors Division
Application	Adapters, Fuels, Natural Gas, Propane, Refrigerant Lines	Specifications Met	SAE J512, SAE J513
Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared	Maximum Operating Pressure	37.9 bar
Brand	Parker	Dimensional Weight	0.5518884892086331 lb
Division	Fluid System Connectors Division	O-Ring Material	Fluorocarbon
Connection 1 Type	Flare	Product Style	Flare to Pipe
Connection 3 Tube Outside Diameter	NA	Shape	90° Forged Elbow
Connection 2 Type	SAE Straight Thread	Connection 3 Type	NA
Connection 1 Thread Size	1-1/16-14 inch	Connection 2 Thread Size	1-1/16-14 inch
Connection 3 Thread Size	NA	Connection 1 Tube Outside Diameter	3/4 inch
Connection 2 Tube Outside Diameter	NA
