| Division | TAIYO Division | Fluid Type | Petroleum-based fluid(When using another fluid,give us such instructions.) |
| Mounting Style | SD,LA,EA,EB,FA,FB,CA,CB,TA,TC | Rod End Styles | Rod eye(T-end),Rod clevis(Y-end)with pin |
| Cushioning Type | Metal fitting system | Screw Tolerance | JIS 6g/6H |
| Seal Material | 1:Nitrile rubber 2:Urethane rubber 3:Fluorocarbon 6:HNBR The rods A of cylinders with bores from 140 and 160mm are made of 1 or 2. | Rod Series | Rod B, Rod A |
| Speed Range | 20-200mm/s | Bellows Material | Standard：Nylon tarpaulin, Semi-standard：Chloroprene, Conex |
| Bore Diameter (mm) | 63, 80, 100, 125,140, 160 | Proof Pressure (MPa) | 21 |
| Temperature Range (C) | -10-+80 (No freezing) | Nominal Pressure (MPa) | 14 |
| Stroke Length Tolerance (mm) | 0-+1.25(200-630mm), 0-+1.4(631-1000mm), 0-+1.6(100-1600mm), 0-+1.8(1601-2500mm), 0-+3.0(2501-3000mm) | Maximum Working Pressure (MPa) | 18 |
| Minimum Operating Pressure (MPa) | Cap side:0.3 Rod side:(A)0.6 (B)0.45 | | |
