| UOM | EA | Installation | IOM 7321 |
| Preventive Maintenance Kit | 12F23C6148ACFR | Function | Normally Closed |
| Specifications Met | UL, CSA Listed Safety Shutoff Valve; CE - Low Voltage, EMC | Port Type | NPT |
| Orifice Size | 3/4 inch | Maximum Fluid Temperature | 180.0 °F |
| Maximum Pressure Differential | 150.0 psi | Seal Material | NBR |
| Power Consumption | 11.0 W | Actuation Type | Direct Lift |
| Input Voltage | 120/60, 110/50 VAC | Minimum Pressure Differential | 0.0 psi |
| Main Flow Coefficient | 5.0 Cv | Body Material | 316 Stainless Steel |
| Port Size | 3/4 inch | Valve Configuration | 2 Way |
| Insulation Class | Class F | Division | Fluid Control Division |
| Maximum Ambient Temperature | 130.0 °F | Media | General Purpose |
| Ingress Protection Rating | NEMA 4,4X | Coil Type | 1/2" NPT Conduit w/ Leads (Incl. Ground Lead) |
| Media | General Purpose | Function | Normally Closed |
| Coil Type | 1/2" NPT Conduit w/ Leads (Incl. Ground Lead) | Port Size | 3/4 |
| Port Type | NPT | Installation | IOM 7321 |
| Orifice Size | 3/4 | Body Material | 316 Stainless Steel |
| Input Voltage | 120/60, 110/50 | Seal Material | NBR |
| Actuation Type | Direct Lift | Insulation Class | Class F |
| Power Consumption | 11.0 | Specifications Met | UL, CSA Listed Safety Shutoff Valve; CE - Low Voltage, EMC |
| Valve Configuration | 2 Way | Main Flow Coefficient | 5.0 |
| Ingress Protection Rating | NEMA 4,4X | Maximum Fluid Temperature | 180.0 |
| Preventive Maintenance Kit | 12F23C6148ACFR | Maximum Ambient Temperature | 130.0 |
| Maximum Pressure Differential | 150.0 | Minimum Pressure Differential | 0.0 |
