Parker 10V2882 - Autoclave 10V Series Needle Valves, 15,000 PSI (1034 bar)

Parker Autoclave's 10V Series needle valves are a non-rotating rising stem design, with working pressures to 15,000 psi (1034 bar). These valves are available in 316 Stainless Steel and utilize the proven Speed Bite single ferrule connection.

AFP Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 10V2882

Products specifications

Attribute name	Attribute value
Connection Type	W125	Division	Instrumentation Products Division
Bore Diameter	0.094	Tube Outside Diameter	1/8
Maximum Operating Pressure	1034	Stem Type	REG
Valve Type	2-Way Angle / Replaceable Seat	Tube O.D. (mm)	3.18 mm
Maximum Working Pressure (psi)	15,000
