| For Fluid Type | Air | Division | TAIYO Division |
| Body Material | Aluminum Alloy | Lubricant | Unnecessary |
| Rod End Type | Rod Eye (T-end) (φ12 to φ100) | Bore Diameter | 12 to 160 |
| Mounting Type | φ12 to φ100: SD (through holes) | Proof Pressure | 1.5 |
| Cushioning Type | None (φ12,φ16) | Operating Speed | 30 to 500 mm/sec (φ12 to φ40) |
| Pressure Rating | 0.1 to 1 MPa (φ12 to φ32) | Stroke Tolerance | 0 to +1.0 mm (φ12 to φ100) |
| Thread Tolerance | JIS 6g/6H | Rod End Thread Type | Male |
| Accessories Included | CB Bracket (φ32 to φ100) | Operating Temperature | -10 to 70 °C (No freezing) |
| Body Material | aluminum alloy | Screw Tolerance | JIS 6g/6H |
| Type | Double Acting Single Rod, Switch set | Fluid Type | Air |
| Lubrication | Unnecessary(But possible) | Proof Pressure (MPa) | 1.5 |
| Rod End Thread Type | Female thread and male thread | Stroke Length Tolerance (mm) | 0-+1.0 |
| Speed Range | 30-500mm/s(φ12-40), 30-300mm/s(φ50-160) | Related Parts | CB bracket(φ30-100) |
| Mounting Style | SD,ST,LA,LB,FA,FB,CA,CB | Rod End Styles | Rod eye(T-end),Rod eye(S-end) with spherical bearing, Rod clevis(Y-end)with pin, Floating joint. |
| Cushioning Type | None(φ12-16), With cushion pads on both ends(Urethane rubber)(φ20-160) | Bore Diameter (mm) | 12, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125, 140, 160 |
| Pressure Range (MPa) | 0.1-1(φ12-32) , 0.05-1(φ40-160) | Temperature Range (C) | -10-+60 (No freezing) |
| Allowable Rotational Torque (N・m) | na | Rotaton Angle Tolerance (degrees) | na |
