Parker 10M1SC10-NNR - Parker Tube Fitting, Male Connector to SAE Straight Thread - A-LOK Series

Parker's two ferrule compression fittings, A-LOK® Series Male Connector to SAE Straight Thread Tube Fittings are designed for leak-free connections in process instrumentation and industrial applications.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 10M1SC10-NNR

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Shape	Straight	Technology	Process Control
Division	Instrumentation Products Division	Brand	A-LOK
Division	Instrumentation Products Division	For Fluid Type	Liquid
Application	Analytical Installations	Industry	Microelectronics
Maximum Operating Temperature	535	Minimum Operating Temperature	-198
Operating Pressure	3000 to 6100	Materials of Construction	Alloy C-276
Product Style	Male Connector to SAE Straight Thread	Specifications Met	EC 79
Length	1.78	Configuration	Tube to O'Ring Seal
O-Ring Dash Number	3-910	Options	n/a
Tube Outside Diameter	5/8" (O.D.)	Thread Size	7/8"-14
