| Division | TAIYO Division | Fluid Type | Petroleum based fluid |
| Speed Range | 1-150mm/s | Related Parts | CD,TA,TC：bracket |
| Mounting Style | SD, LA, LB, FA, FB, CA, CB, CC, TC | Proof Pressure | 1.5 |
| Rod End Styles | Rod eye(T-end),Rod eye(S-end),Rod clevis(Y-end)with pin, Floating joint | Cushioning Type | None |
| Screw Tolerance | JIS 6g/6H | Bellows Material | Nylon tarpaulin(Standard), Chloroprene(Semi-standard), Conex(Semi-standard) |
| Bore Diameter (mm) | 32, 40, 50, 63, 80, 100 | Temperature Range (C) | -10-+70(No freezing) |
| Stroke Length Tolerance (mm) | 0-250:0-+1.0 251-1000:0-+1.5 1001-1500:0-+2.0 | Pressure Range (MPa) | 0.2-1.0 |
