| Division | TAIYO Division | Type | Double Brake Type |
| Fluid Type | Air | Lubrication | Necessary(Use JIS K 2213 Class 1 additive-free turbine oil VG32 or its equivalent.) |
| Speed Range | 50-300mm/s | Related Parts | CB bracket |
| Mounting Style | SD, LA, LB, FA, FB, CA, CB, CC | Rod End Styles | Rod eye(T-end),Rod eye(S-end),Rod clevis(Y-end)with pin, Floating joint |
| Cushioning Type | With cushions on both ends(With needle removal preventing mechanism) | Bellows Material | Nylon tarpaulin(Standard), Chloroprene(Semi-standard), Conex(Semi-standard) |
| Bore Diameter (mm) | 40, 50, 63, 80, 100 | Pressure Range (MPa) | 0.35-1.0 |
| Temperature Range (C) | +5-+60 | Cushioning Stroke (mm) | 16(φ40), 20(φ50-63), 25(φ80-100) |
| Maximum Load Capacity | 34kg(φ40), 53kg(φ50), 85kg(φ63), 138kg(φ80), 215kg(φ100) | Stop Repeatability (mm) | ±2 *Load weight:Repeatability at maximum weight of load, Speed:Repeatability at maximum transferring speed(300mm/s) |
| Brake operating direction | Both directions | Brake Release Pressure (Mpa) | 0.35 (0.4 only for φ50) |
