Parker 10791N-8-8 - Permanent Fittings for PTFE Hose - 91/91N

Parker's 91/91N Series fittings are used with 919/919B, 919J, 919U, 929/929B, and 929BJ PTFE hoses from the Parflex division.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 10791N-8-8

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Brand	Parker	Shape	Straight
Division	Parflex Division	Technology	Fluid & Gas Handling
Maximum Operating Pressure	207 bar	Application	Chemical Transfer
Specifications Met	N/A	Coating	Chromium 6 Free-plated
Division	Parflex Division	Product Type	Hose Fittings
Configuration	Hose to Port	Connection 1 Size	-8 (Size)
Connection 1 Type	Hose	Tube Outside Diameter	n/a
For Fluid Type	Water	Connection 2 Size	1/2"-14 inch Thread
Product Series	91N	Industry	Semiconductor
Connection Length	1-1/8 inch Cut-off allowance (see drawing legend B)	Dimensional Weight	0.0567 lb
Connection 2 Type	Swivel	Hex Size	3/4 inch (see drawing legend J)
Hex Size 1	1 inch (see drawing legend H)	Body Material	Steel (Nut and Shell)
Fitting Length	46 mm	Hose I.D. (inch)	0.406"
Connection 2 Size	1/2"-14	Length (inch)	1.83"
Product Style	Female NPSM Pipe - Swivel - Straight (60° Cone)
