Parker 100916 - HONEYCOMB™ HFT Wound Depth Liquid Filter Cartridge

Honeycomb™ wound depth filter cartridges remove contaminants from a wide range of liquid applications. Parker strings are known for superior quality and performance. Available from 0.5 to 150 micron ratings with a variety of string materials.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 100916

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Division	Industrial Process Filtration Division	Brand	Parker
Product Type	Filter Cartridge	Division	Industrial Process Filtration Division
Technology	Filtration	Application	Liquid Particulate Filtration
Flow Direction	Outside-to-inside	Quantity per Box	30
Product Series	HFT	Filter Construction	Wound String
Nominal Inside Diameter	1"	Maximum Pressure Differential	60 PSID
Changeout Pressure Differential	30 PSID	Core Material	Tin-Plated Steel
Micron Rating	50	End Cap Material	N/A
End Cap Configuration	DOE - Double Open End	Cartridge Length	10"
Model Number	ELMT 11R10	Industry	Oil & Gas and Industrial
Packaging	Standard	Seal Material	N/A
Filter Material	Cotton (FDA)	Core Cover Material	N/A
Nominal Outside Diameter	2.4375"	Maximum Operating Temperature	250 F

Product resources

Literature and Reference Materials

HONEYCOMB™ HFT Wound Depth Liquid Filter Cartridge (PDF)
