*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker 10 FNTX-SS - Triple-Lok® 37° Flare JIC Tube Fittings and Adapters

Parker Triple-Lok 37° Flare JIC Tube Fittings and Adapters are a reliable leak-free metal to metal connection solution for most high pressure hydraulic applications.

AFP Availability:	Quote Required
Partner Available:	90 In Stock

Brand Parker

Part No. 10 FNTX-SS

$48.97/each

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 4 Tube Outside Diameter	na
Connection 1 Size	Female 37° Flare	Body Material	Stainless Steel
Connection 1 Tube Outside Diameter	5/8 inch	Connection 2 Tube Outside Diameter	na
Connection 3 Size	na	Connection 2 Thread Size	na
Shape	Cap	Connection 3 Thread Size	na
Maximum Dynamic Pressure	6000 psi	Specifications Met	SAE J514
Connection 4 Size	na	Dimensional Weight	0.039568345323741004 lb
O-Ring Material	na	Division	Tube Fittings Division
Connection Type	37° Flare	Connection 2 Size	na
Connection 3 Tube Outside Diameter	na

Product resources

Literature and Reference Materials

Compliance, Certifications & Safety

Lloyds Register Zertifikat LR2382868TA-Triple-Lok (PDF)
