Parker 009-0347-900 - Pulse Valves – Miniature High Speed High Vacuum Dispense

Parker's Pulse Valves combine extreme pressures, tight leak specifications and wide temperature ranges with an unmatched compact size package and fast response.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 009-0347-900

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Width	1.33 inch	Length	1.80 inch
Weight	79.4 g	Function	Normally Closed (NC)
Flow Rate	n/a	Leak Rate	1 x 10-7 Atm Cc/sec Helium
Orifice Size	0.020 inch	Body Material	Stainless Steel 316
Configuration	n/a	Input Voltage	20 VDC
Mounting Type	Mounting Screw	Seal Material	FFKM
Actuation Type	Solenoid	Control Method	Current or Voltage
For Fluid Type	Gases	Operation Type	Electronic
Connection Size	A-LOK® Compression	Connection Type	Flange Body
Shipping Weight	1	Maximum Flow Rate	n/a
Power Consumption	12.1 W	Max Order Quantity	9
Standard Lead Time	20	Division	Precision Fluidics Division
Industry Application	Gas Pulse Generation for Laser Spectroscopy	Electrical Connection	12" Wire Leads
Out of Stock Lead Time	40	Maximum Operating Pressure	1250 psi
Maximum Operating Temperature	221 °F	Minimum Operating Temperature	4 °C
MetaTitle	Pulse Valves to High pressure and Temperature Low Leak Rate Inert Valve to Parker	MetaKeywords	Ultra Low Leak Rate Valve
Response Time	< 2 ms Cycling	MetaDescription	fast response and extremely low leak rates make these ideal Gas Pulse valves for Laser Spectroscopy
Outlet Port Type	Flange	Orifice Size	.020"
Voltage (VDC)	20	Outlet Flange	Cone
Poppet Material	Vespel
