Parker 00-020439 - TRU-PLEAT™ PS Liquid Filter Cartridge

Tru-Pleat™ PS filter cartridges remove contaminants from a wide range of liquid applications. The pleated style cartridges are made using synthetic media and hardware. Available from 0.5 to 70 micron rating options with variety of end cap options.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 00-020439

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Brand	Parker	Division	Industrial Process Filtration Division
Industry	Oil & Gas	Technology	Filtration
Application	Liquid Particulate Filtration	Product Type	Filter Cartridge
Flow Direction	Outside-to-inside	Division	Industrial Process Filtration Division
Filter Construction	Pleated	pH Range	2-14
Model Number	ELMT PS-240-S1C-10LB	Body Material	Polypropylene
Core Material	Polypropylene	Micron Rating	10
Product Series	PS	Filter Material	Polypropylene
Cartridge Length	40"	End Cap Material	Polypropylene
End Cap Configuration	SOE - Closed top w/ CS spring, open bottom	Nominal Inside Diameter	1.1"
Nominal Outside Diameter	2.5"	Maximum Operating Temperature	180 F
Maximum Pressure Differential	50 psid	Seal Material	Buna-N
Changeout Pressure Differential	20 PSID	Quantity per Box	15

Product resources

Literature and Reference Materials

TRU-PLEAT™ PS Liquid Filter Cartridge (PDF)
