Flow Control Valve - 3251 Series
*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.
The 3251 flow control is an ideal solution to cylinder speed control where space is at a premium. Costly fittings, connections and piping expenses can be eliminated because the valve can rotate 360 degrees, and the piping alignment can be in any direction. The 1/8" model can be rotated after final assembly. The 3251 Flow Controls are standard male to female ported and can be ordered with optional Prestolok fittings in place of the female port. This allows for quick connection and eliminates the need for separate tube fittings. Flow is adjusted with an allen wrench and locked with a nut for tamper protection.
Markets:
• Factory Automation
• Heavy Industries
Features/Benefits:
• Heavy duty brass construction
• Eliminates in-line components
• Space saving
Applications:
• General purpose industrial pneumatics
• Cylinder speed control
| Action | Part No. | Availability | Partner Available | Price | UOM | Division | Media | Options | Flow Rate | Lubricant | Port Size | Port Type | Product Type | Body Material | Mounting Type | Seal Material | Needle Material | Flow Coefficient | Operating Pressure | Operating Temperature | Operation Type | Port Connection | Port Size (inch) | Port Connection | Thread Size (Inch) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 032510125 | Quote Required | 21 In Stock | $0.01 | EA | Pneumatic Division | Air | Push-to-Connect Fittings Available | 14 to 88 SCFM (metered) | None | 1/8 | NPT | Flow Control | Brass | Rotating Right Angle | Nitrile Butadiene Rubber (NBR) | Brass | 0.26 to 1.64 Cv (metered) | 0 to 125 | -18 to 60 | Hex Head | Male to Female | 1/8 | Male to Female | 1/8 | |
| 032510250 | Quote Required | 3 In Stock | $0.01 | EA | Pneumatic Division | Air | Push-to-Connect Fittings Available | 14 to 88 SCFM (metered) | None | 1/4 | NPT | Flow Control | Brass | Rotating Right Angle | Nitrile Butadiene Rubber (NBR) | Brass | 0.26 to 1.64 Cv (metered) | 0 to 125 | -18 to 60 | Hex Head | Male to Female | 1/4 | Male to Female | 1/4 | |
| 032510375 | Quote Required | $0.01 | EA | Pneumatic Division | Air | Push To Connect Fittings Available | 14 to 88 (metered) / 11 to 75 (free flow) SCFM | None | 3/8 | NPT | Flow Control | Brass | Rotating Right Angle | Buna N | Brass and Acetal | 0.26 to 1.64 (metered) / 0.20 to 1.41 (free flow) Cv | 0 - 125 | -18° to +60° °C | Hex Head | Male to Female, Male to Quick Tube Connect | 3/8 | Male to Female | 3/8 | ||
| 032510500 | Quote Required | 2 Limited Stock | $0.01 | EA | Pneumatic Division | Air | Push To Connect Fittings Available | 14 to 88 (metered) / 11 to 75 (free flow) SCFM | None | 1/2 | NPT | Flow Control | Brass | Rotating Right Angle | Buna N | Brass and Acetal | 0.26 to 1.64 (metered) / 0.20 to 1.41 (free flow) Cv | 0 - 8 bar | -18° to +60° °C | Hex Head | Male to Female, Male to Quick Tube Connect | 1/2 | Male to Female | 1/2 | |
| 032511215 | Quote Required | TBD | Pneumatic Division | Air | Push-to-Connect Fittings Available | 14 to 88 SCFM (metered) | None | 5/32 | NPT | Flow Control | Brass | Rotating Right Angle | Nitrile Butadiene Rubber (NBR) | Brass | 0.26 to 1.64 Cv (metered) | 0 to 125 | -18 to 60 | Hex Head | Male to Female | 5/32 | Male to Quick Tube Connect | 1/8 | |||
| 032511225 | Quote Required | $0.01 | EA | Pneumatic Division | Air | Push-to-Connect Fittings Available | 14 to 88 SCFM (metered) | None | 1/4 | NPT | Flow Control | Brass | Rotating Right Angle | Nitrile Butadiene Rubber (NBR) | Brass | 0.26 to 1.64 Cv (metered) | 0 to 125 | -18 to 60 | Hex Head | Male to Female | 1/4 | Male to Quick Tube Connect | 1/8 | ||
| 032512525 | Quote Required | 4 In Stock | $0.01 | EA | Pneumatic Division | Air | Push-to-Connect Fittings Available | 14 to 88 SCFM (metered) | None | 1/4 | NPT | Flow Control | Brass | Rotating Right Angle | Nitrile Butadiene Rubber (NBR) | Brass | 0.26 to 1.64 Cv (metered) | 0 to 125 | -18 to 60 | Hex Head | Male to Female | 1/4 | Male to Quick Tube Connect | 1/4 | |
| 032512538 | Quote Required | 2 Limited Stock | $0.01 | EA | Pneumatic Division | Air | Push-to-Connect Fittings Available | 14 to 88 SCFM (metered) | None | 3/8 | NPT | Flow Control | Brass | Rotating Right Angle | Nitrile Butadiene Rubber (NBR) | Brass | 0.26 to 1.64 Cv (metered) | 0 to 125 | -18 to 60 | Hex Head | Male to Female | 3/8 | Male to Quick Tube Connect | 1/4 | |
| 032513838 | Quote Required | 2 Limited Stock | $0.01 | EA | Pneumatic Division | Air | Push-to-Connect Fittings Available | 14 to 88 SCFM (metered) | None | 3/8 | NPT | Flow Control | Brass | Rotating Right Angle | Nitrile Butadiene Rubber (NBR) | Brass | 0.26 to 1.64 Cv (metered) | 0 to 125 | -18 to 60 | Hex Head | Male to Female | 3/8 | Male to Quick Tube Connect | 3/8 |
